T echnology:
4 IN 1 (CVI, TVI, AHD and analogue)
Camera
type :
PTZ
Series:
HiWatch
Sensor: CMOS®
Sensor resolution: 1920 x 1080
Sensor size: 1/2.8"
Electronic shutter speed: 1/1s ~ 1/10,000s
Minimum illumination: 0.005Lux
VIDEO (CAMERAS)
Video resolution: 2 Megapixels
Frames per second: 25fps@1080P
Video output: 1 x BNC switchable HD-CVI / HD-TVI / AHD / CVBS with PFM820 accessory (not included)
Day / night mode: Automatic / Manual
Digital zoom: 16x
Privacy mask: Up to 8 zones
3D-NR: Yes
AGC: Yes
WDR: WDR (120dB)
DISTANCE DORI
Detect (lens open): 64 m
Detect (lens closed): 1420m
Observe (Objective open): 27 m
Observe (Objective closed): 565m
Recognize (open objective): 14 m
Recognize (Objective closed): 280m
Identify ( Open lens ): 6.5 m
Identify (Objective closed): 140m
OCULAR
Lens Type: Optical Zoom
Focal length: 4.8mm ~ 120mm
Maximum diaphragm aperture: F/1.6 ~ F/3.5
Viewing angle: 57.6° ~ 2.5°
Minimum focusing distance: 100mm ~ 1500mm
Autofocus: Yes
Optical zoom: 25x
Zoom speed: 3.2 s
NIGHT VISION
Night vision distance: 100m
PTZ
Row Pan/Tilt: Horizontal 360° / Vertical 90° with autoflip
Manual control speed: Horizontal 80º/s / Vertical 80º/s
Speed: Horizontal 80º/s / Vertical 80º/s
Memoirs: 256
PTZ mode: 10 turns between established points, 5 rounds
Speed setting: Adapted to the speed of the human eye
Protocol: Pelco-P / Pelco-D protocol
RS485: 1 Input
MATERIAL AND DIMENSIONS
Material: Metal
Dimensions: 290 x 165.9 (Ø) mm
Net weight: 2000 g
ATMOSPHERE
Operating temperature: -30°C ~ +65°C
Degree of protection: IP66
Use: Interior / Exterior
Maximum humidity: 95%
FOOD AND CONSUMPTION
Power supply mode: DC
Voltage: 12V
Consumption (w): 20W
Amperage: 1600mA
