DAHUA IP recorder for 4 channels and 12 mpx resolution / Reference NVR2104HS-I2

IP Channels: 4

Video compression: H.265 / H.264 Recording mode : Manual / Programming / Motion detection / Alarm Audio compression: PCM / G.711A / G.711U / G.726 Resolutions: 12Mpx / 8Mpx / 5Mpx / 4Mpx / 3Mpx / 2Mpx / 1Mpx / D1 Input bandwidth: 80Mbps Output bandwidth: 60Mbps Maximum recording resolution: 12 Mpx

HDMI output number: 1 VGA output number: 1 HDMI resolution: 4K (8 Megapixels) Similar video signals: HDMI and VGA

Audio Inputs: 1 Audio outputs: 1

Admitted hard drive number: 1 Maximum hard disk size (unit): 10 TB HDD type: 3.5" SATA

USB2.0: 2

Simultaneous cameras in reproduction: 1/4 Playback functions: Play / Pause / Stop / Fast forward / Fast backward / Rewind / Play by frame / Full screen / Backup (cut/file) / Partially enlarge / Audio on/off Backup Mode: USB Device

RJ45 port number: 1 RJ45 speed: 10 / 100 Mbps Mobile devices: Android / IOS (Apple) ONVIF: Yes Remote viewing: Web browser (ActiveX) / Smartphone App / Smart PSS Software Software: SmartPSS App: iDMSS / gDMSS

Processor: Industrial-grade integrated processor Operating system: Embedded LINUX Smart fan: Yes

Line crossing: Yes Intrusion: Yes Privacy mask: Yes Face detection: Yes SMD PLUS: Yes, 4 channels (human/vehicle classification) Motion detection: Yes

Number of channels with analysis: 1 channel

Number of faces: 4 faces processed per second Number of channels with facial recognition: 1 channel of video facial recognition Database management: Up to 10 databases with 5000 faces in total / Allows to designate name / gender / date of birth / nationality / address / Identification information can be added to each face image

Material: Metal Dimensions: 260 x 232.7 x 47.6mm Net weight: 810g Weight with packaging: 1380 g Installation: Desktop Chassis: Compact 1U

Operating temperature: -10ºC ~ 55ºC Use: Interior Maximum humidity: 93%

Power supply mode: DC Voltage: 12V Consumption (w): 10W Amperage: 1500mA

---
