DAHUA IP recorder for 16 channels and 12 mpx resolution / Reference NVR2216-16P-I2

IP Channels: 16

Video compression : H.265 / H.264 Recording mode: Manual / Programming / Motion detection / Alarm Audio compression: PCM / G.711A / G.711U / G.726 Resolutions: 12Mpx / 8Mpx / 5Mpx / 4Mpx / 3Mpx / 2Mpx / 1Mpx / D1 Input Bandwidth: 144Mbps Output bandwidth: 72Mbps Maximum recording resolution: 12 Mpx

HDMI output number: 1 VGA output number: 1 HDMI resolution: 4K (8 Megapixels) Similar video signals: HDMI and VGA

Audio Inputs: 1 Audio outputs: 1

Number of hard drives admitted: 2 Maximum hard disk size (unit): 10 TB HDD type: 3.5" SATA

USB2.0: 2 Alarm input: 4 Alarm output: 2

Simultaneous cameras in reproduction: 1 / 4 / 8 / 9 / 16 Playback functions: Play / Pause / Stop / Fast forward / Fast backward / Rewind / Play by frame / Full screen / Backup (cut/file) / Partially enlarge / Audio on/off Backup Mode: USB Device Smart search: Yes Synchronized playback: 16

RJ45 port number: 1 RJ45 speed: 10 / 100 / 1000Mbps Mobile devices: Android / IOS (Apple) ONVIF: Yes Remote vision: Web browser (ActiveX) / Smartphone app / Smart PSS software PoE ports: 16 PoE type: 802.3af PoE Consumption: 25.5W per Port / 130W total Software: SmartPSS App: iDMSS / gDMSS

Processor: Integrated industrial-grade processor Operating system: Embedded LINUX Smart fan: Yes

Privacy mask: Yes Face detection: Yes SMD PLUS: Yes, 4 channels (human/vehicle classification) Motion detection: Yes

Number of channels with analysis: 1 channel

Number of faces: 4 faces processed per second Number of channels with facial recognition: 1 channel of video facial recognition Database management: Up to 10 databases with 5000 faces in total / Allows to designate name / gender / date of birth / nationality / address / Identification information can be added to each face image

Material: Metal Dimensions: 375 x 329.3 x 53 mm Net weight: 2650 g Weight with packaging: 4000 g Installation: Desktop / Rack Chassis: 1U

Operating temperature: -10ºC ~ 55ºC Use: Interior Maximum humidity: 93%

Power supply mode: AC Voltage: 100V ~ 240V Consumption (w): 10W Amperage: 3500mA

---
