DAHUA IP recorder for 8 channels and 12 mpx resolution / Reference NVR2108-S3

IP channels: 8

Video compression: H.265 / H.264 Recording mode: Manual / Programmable / Motion detection / Alarm Audio compression: PCM / G.711A / G.711U / G.726 Resolutions: 12Mpx / 8Mpx / 5Mpx / 4Mpx / 3Mpx / 2Mpx / 1Mpx / D1 Input Bandwidth: 80Mbps Output Bandwidth: 60Mbps Maximum recording resolution: 12 MP

HDMI output number: 1 Number of VGA outputs: 1

Audio inputs: 1 Audio outputs: 1

Number of hard disks allowed: 1 Maximum hard disk size (unit): 16 TB HDD Type: 3.5" SATA

USB2.0: 2

Simultaneous cameras in reproduction: 1 / 4 / 8 / 9 Playback functions: Play / Pause / Stop / Fast forward / Fast backward / Rewind / Play by frame / Full screen / Backup (cut/file) / Partially enlarge / Audio on/off Backup Mode: USB Device Smart Search: Yes Synchronized playback: 8

RJ45 port number: 1 RJ45 speed: 10 / 100 Mbps Mobile devices: Android / IOS (Apple) ONVIF: Yes Remote vision: Web (ActiveX) / Smartphone App / Smart PSS Software Software: SmartPSS App: iDMSS / gDMSS

Processor: Integrated industrial-grade processor Operating system: Embedded LINUX

Privacy Mask: Yes SMD PLUS: Yes, 4 channels (man/vehicle classification) Motion detection: Yes

Number of channels with analysis: 4 Channels

Material: Plastic Dimensions: 204.6 x 206.4 x 45.6mm Net weight: 420g Weight with packaging: 1020 g Installation: Desktop / Rack Chassis: Smart 1U

Working Temperature: -10ºC~55ºC Use: Indoor Max Humidity: 93%

Power mode: DC Voltage: 12V Consumption (w): 10W Amperage: 1500mA

---
